Ceiling installation Direct light emission Compliant with the directive for electromagnetic compatibility 89/336 / EEC; 73/23 / EEC Insulation class II Flammable surfaces suitable for installation
Chromatic rendered index ≥80 Lifetime: 50000 hours Photobiological risk Degree of protection IP40
Mountings:
Surface mounted fitting
Light emission:
Direct
Symmetric
Body:
Made of white painted die-cast aluminium
Optical device:
Diffuser in opal methacrylate
Light source:
• LE CRI ≥80 Ra
• 3000K
• 4000K
• Lifetime (Ta=25°C) 50000h L70B50
Wiring:
Class II
Feeding 100~240 V / 50-60 Hz
Performance data:
• Protection level IP43
Marks:
CE
Regulations:
EN 60598-1
EN 60598-2-1
EN 62031
Photobiological safety of lamps and lamp system:
EN 62471
IEC/TR 62778
Directives:
2014/35/UE
2014/30/UE
VERSIONS UPON REQUEST (if possible)
• Dimmable electronic ballast PUSH
• Dimmable electronic ballast 1-10V
• Dimmable electronic ballast DALI

Download

ds_8873_MILANO_SQUARE

Data Sheet: MILANO SQUARE - 8873

Download (650.68KB)

Eulumdat: 8873

Download (40.68KB)
